ME132導軌式多迴路3相多功能電表
電洽
ME132是一款高效能智慧電能表，支援多迴路和單迴路應用的精確計量，適用於三相四線制電網系統。它配備RS485/Modbus-RTU有線協議，確保資料傳輸穩定可靠。
此模組寬度僅 1P (18mm)，採用緊湊的 DIN 導軌安裝設計，節省空間並可靈活部署。配套的羅氏線圈可直接套在母線、銅條或電纜上，無需斷電或拆卸線路，即可輕鬆安裝，顯著提高施工效率和安全性。
Main characteristics
ME132measures the following values in accordance with the IEC 61557-12
standard PMD-II/DD/K70/1:
Energy (4 quadrants):
Active energy (kWh): total and partial, delivered and received.
Active energy per phase (kWh): total and partial, delivered and received.
Reactive energy (kVARh): total and partial, delivered and received.
Reactive energy per phase (kVARh): total and partial, delivered and received.
Apparent energy (kVAh): total and partial.
Apparent energy per phase (kVAh): total and partial.
Power:
Active power (W): total and per phase.
Reactive power (VAR): total and per phase.
Apparent power (VA): total and per phase.
Voltages (V):
phase-to-phase (U12, U23, U31) and phase-to-neutral (V1N, V2N, V3N).
Currents (A):
per phase (I1, I2, I3), calculated neutral current when connected (IN).
Frequency (Hz).
Power factor: total and per phase.
Harmonics:
Percentage and value of 1-51st harmonics for each phase of current and voltage
此模組寬度僅 1P (18mm)，採用緊湊的 DIN 導軌安裝設計，節省空間並可靈活部署。配套的羅氏線圈可直接套在母線、銅條或電纜上，無需斷電或拆卸線路，即可輕鬆安裝，顯著提高施工效率和安全性。
Main characteristics
ME132measures the following values in accordance with the IEC 61557-12
standard PMD-II/DD/K70/1:
Energy (4 quadrants):
Active energy (kWh): total and partial, delivered and received.
Active energy per phase (kWh): total and partial, delivered and received.
Reactive energy (kVARh): total and partial, delivered and received.
Reactive energy per phase (kVARh): total and partial, delivered and received.
Apparent energy (kVAh): total and partial.
Apparent energy per phase (kVAh): total and partial.
Power:
Active power (W): total and per phase.
Reactive power (VAR): total and per phase.
Apparent power (VA): total and per phase.
Voltages (V):
phase-to-phase (U12, U23, U31) and phase-to-neutral (V1N, V2N, V3N).
Currents (A):
per phase (I1, I2, I3), calculated neutral current when connected (IN).
Frequency (Hz).
Power factor: total and per phase.
Harmonics:
Percentage and value of 1-51st harmonics for each phase of current and voltage
